30CrMnSi Steel Alloy Structural Steel Round Bar For Industrial Construction

Model:30CrMnSi （30ΧΓСΑ）Steel Alloy
Brand:SHUNBEI
MOQ:10 TON
As a common metal material, Alloy round steel is widely used in construction, machinery manufacturing, aerospace and other fields.

30CrMnSi Alloy Steel Round Bar application parameters:

Product Name	30CrMnSi（30ΧΓСΑ）Steel Alloy Structural Steel Round Bar
Length	6 meters;12 meters; As required.
Diameter	Φ4-1600mm, if you others, please contact us for more.
Standard	GB,GOST,etc. ; Test Reports of Material & SGS Inspection Available
Technique	Hot rolled (HR) Cold rolled(CR) Cast
Main Grades:	10# 20# 35# 45# 50# 60# Q345B Q345C Q345D Q345E,Q235B Q235R Q355B ST12 ST37 ST52 DT4C 40cr T10 etc.
MOQ	1 ton. Sample order acceptable.
Lead Time	Within 5-20days after receiving deposit. If in large tons, please contact us for confirmation.
Export packing	Waterproof paper protected, steel strip packed stably, and fixed well. Standard Export Seaworthy Package. Suit for all kinds of transportation means; or as required

30CrMnSi Alloy Steel Chemical Composition:

Element	Composition (%)
Carbon (C)	0.27-0.34
Silicon (Si)	0.90-1.20
Manganese (Mn)	0.80-1.10
Phosphorus (P)	≤0.035
Sulfur (S)	≤0.035
Chromium (Cr)	0.80-1.10
Nickel (Ni)	≤0.30
Copper (Cu)	≤0.30
Molybdenum (Mo)	≤0.15

Product Description

30CrMnSi alloy structural steel is high strength Quenched and tempered steel. It has high strength and toughness, high harden-ability, moderate plastic deformation and good processing. It has temper brittleness and transverse impact toughness. The weld-ability is better, but when the thickness is greater than 3mm, the 30CrMnSi steel should be preheated to 150 C and do heat treatment after welding, and be used after Quenching and tempering.

Application

30CrMnSi steel is used to manufacture all kinds of important parts of high load and high speed, such as gear, shaft, clutch, sprocket, wheel shaft, shaft sleeve, bolt, nut and so on. 30CrMnSi alloy structural steel is also used to make parts with wear-resistant, working temperature not high, the welded components of variable load, such as the blades of high pressure blower, valve plate, etc.
